Mg-Cr共掺LiNi0.5Mn1.5O4 正极材料的制备及电化学性能

doi:10.19799/j.cnki.2095-4239.2024.1131

摘要/Abstract

摘要：

LiNi_0.5Mn_1.5O₄(LNMO)是一种具有高工作电压(4.7 V)、高能量密度(650 Wh/kg)和成本低廉优势的正极材料。然而受到电解液分解、Jahn-Teller效应和Mn溶解等因素的影响，LNMO正极材料存在容量衰减快、倍率性能差等问题。为此，本工作采用水热法制备了Mg-Cr共掺杂的LMMO材料，研究了Mg、Cr掺杂量对LNMO电化学性能的影响。结果表明，当Mg、Cr掺杂量各为2%时，LMMO电极表现出最为优异的电化学性能。其在0.1C倍率下的放电比容量为137.3 mAh/g；在1C倍率下循环200次后，容量保持率为85.74%，明显高于原始LNMO的116.5 mAh/g和51.82%。此外，Mg-Cr共掺杂的LMMO电极在0.5 C下放电容量可达121.8 mAh/g，在5 C下可达94.3 mAh/g。机理探究表明，Mg和Cr的共掺杂有利于形成无序的Fd $3 ¯$ m相，提高材料的电导率，降低电极电荷转移电阻。本研究提供了一种改善LNMO性能的简单策略，为高性能锂离子电池正极材料的设计提供了参考。

关键词: LiNi_0.5Mn_1.5O₄, 正极材料, Mg-Cr共掺杂, 电化学性能

Abstract:

LiNi_0.5Mn_1.5O₄ (LNMO) is a cathode material known for its high operating voltage (4.7 V), high energy density (650 Wh/kg), and low cost. However, owing to factors such as electrolyte decomposition, Jahn-Teller effect, and Mn dissolution, LNMO cathode materials usually demonstrate rapid capacity fading and poor rate capability. To improve their electrochemical performance, we prepared Mg-Cr co-doped LMMO materials via the hydrothermal method and studied the influence of Mg-Cr co-doping content on the electrochemical performance of the LNMO cathode. Our experimental results show that the optimal electrochemical performance is achieved when the doping content of Mg and Cr is 2% each. The Mg-Cr co-doped LMMO cathode exhibits a discharge capacity of 137.3 mAh/g at 0.1C rate and a capacity retention of 85.74% after 200 cycles at 1C rate, markedly outperforming the original LNMO cathode (116.5 mAh/g and 51.82%, respectively). In addition, it delivers capacities of 121.8 mAh/g at 0.5C and 94.3 mAh/g at 5C. Mechanistic analysis shows that Mg-Cr co-doping promotes the formation of a disordered Fd $3 ¯$ m phase, enhancing the electronic conductivity of LMMO material and reducing the electrochemical polarization and charge transfer resistance of the cathode. This study presents a simple method to improving the electrochemical performance of LNMO cathode and offers valuable insights for designing high-performance lithium-ion battery cathode materials.

Key words: LiNi_0.5Mn_1.5O₄, cathode material, Mg-Cr co-doping, electrochemical characteristic

中图分类号:

TM 911

刘博宇, 王腾飞, 庞青, 陈凯宇, 望红玉. Mg-Cr共掺LiNi_0.5Mn_1.5O₄ 正极材料的制备及电化学性能[J]. 储能科学与技术, 2025, 14(3): 1097-1106.

Boyu LIU, Tengfei WANG, Qing PANG, Kaiyu CHEN, Hongyu WANG. Preparation and electrochemical performance of Mg-Cr co-doped LiNi_0.5Mn_1.5O₄ cathode material[J]. Energy Storage Science and Technology, 2025, 14(3): 1097-1106.

图/表 9

图1

图2

图3

图4

图5

图6

图7

图8

图9

参考文献 32

1	刘博宇, 庞青, 王腾飞, 等. 高镍三元正极材料LiNi_0.8Co_0.1Mn_0.1O₂在高压下的研究进展[J]. 储能科学与技术, 2024, 13(11): 3784-3795. DOI: 10.19799/j.cnki.2095-4239.2024.0432.
	LIU B Y, PANG Q, WANG T F, et al. Advancements in the modification of high-voltage Ni-rich ternary cathode material LiNi_0.8Co_0.1Mn_0.1O₂ for lithium-ion batteries[J]. Energy Storage Science and Technology, 2024, 13(11): 3784-3795. DOI: 10.19799/j.cnki.2095-4239.2024.0432.
2	李晋, 王青松, 孔得朋, 等. 锂离子电池储能安全评价研究进展[J]. 储能科学与技术, 2023, 12(7): 2282-2301. DOI: 10.19799/j.cnki.2095-4239.2023.0252.
	LI J, WANG Q S, KONG D P, et al. Research progress on the safety assessment of lithium-ion battery energy storage[J]. Energy Storage Science and Technology, 2023, 12(7): 2282-2301. DOI: 10.19799/j.cnki.2095-4239.2023.0252.
3	伍鹏, 郭盼龙, 郭力铭, 等. 高镍正极材料LiNi_0.83Co_0.12Mn_0.05O₂双包覆改性及软包锂离子电池应用研究[J]. 材料研究与应用, 2022, 16(5): 812-818. DOI: 10.20038/j.cnki.mra.2022.000514.
	WU P, GUO P L, GUO L M, et al. Dual-coating of LiNi_0.83Co_0.12Mn_0.05O₂ with nanosized ZrO₂ and B₂O₃ for lithium-ion pouch cell application[J]. Materials Research and Application, 2022, 16(5): 812-818. DOI: 10.20038/j.cnki.mra.2022.000514.
4	李军, 黄慧民, 李大光, 等. 锂离子电池纳米阴极材料的研究进展[J]. 材料研究与应用, 2007, 1(3): 165-168. DOI: 10.3969/j.issn.1673-9981.2007.03.002.
	LI J, HUANG H M, LI D G, et al. Research progress of nano-scale cathode materials in lithium ion battery[J]. Materials Research and Application, 2007, 1(3): 165-168. DOI: 10.3969/j.issn.1673-9981.2007.03.002.
5	FU T J, LU D, YAO Z Q, et al. Advances in modification methods and the future prospects of high-voltage spinel LiNi_0.5Mn_1.5O₄ — A review[J]. Journal of Materials Chemistry A, 2023, 11(26): 13889-13915. DOI: 10.1039/D3TA01777J.
6	SANTHANAM R, RAMBABU B. Research progress in high voltage spinel LiNi_0.5Mn_1.5O₄ material[J]. Journal of Power Sources, 2010, 195(17): 5442-5451. DOI: 10.1016/j.jpowsour. 2010.03.067.
7	HU M, PANG X L, ZHOU Z. Recent progress in high-voltage lithium ion batteries[J]. Journal of Power Sources, 2013, 237: 229-242. DOI: 10.1016/j.jpowsour.2013.03.024.
8	VERSACI D, COLOMBO R, MONTINARO G, et al. Tailoring cathode materials: A comprehensive study on LNMO/LFP blending for next generation lithium-ion batteries[J]. Journal of Power Sources, 2024, 613: 234955. DOI: 10.1016/j.jpowsour. 2024.234955.
9	GAO C, LIU H P, BI S F, et al. Insights for the new function of N,N-dimethylpyrrolidone in preparation of a high-voltage spinel LiNi_0.5Mn_1.5O₄ cathode[J]. ACS Applied Materials & Interfaces, 2021, 13(17): 20014-20023. DOI: 10.1021/acsami.1c01283.
10	TALYOSEF Y, MARKOVSKY B, SALITRA G, et al. The study of LiNi_0.5Mn_1.5O₄ 5 V cathodes for Li-ion batteries[J]. Journal of Power Sources, 2005, 146(1/2): 664-669. DOI: 10.1016/j.jpowsour.2005.03.064.
11	CHANG B, YUN D H, HWANG I, et al. Carrageenan as a sacrificial binder for 5 V LiNi_0.5Mn_1.5O₄ cathodes in lithium-ion batteries[J]. Advanced Materials, 2023, 35(45): e2303787. DOI: 10.1002/adma.202303787.
12	LIANG G M, WU Z B, DIDIER C, et al. A long cycle-life high-voltage spinel lithium-ion battery electrode achieved by site-selective doping[J]. Angewandte Chemie International Edition, 2020, 59(26): 10594-10602. DOI: 10.1002/anie.202001454.
13	GONG J J, YAN S P, LANG Y Q, et al. Effect of Cr³⁺ doping on morphology evolution and electrochemical performance of LiNi_0.5Mn_1.5O₄ material for Li-ion battery[J]. Journal of Alloys and Compounds, 2021, 859: 157885. DOI: 10.1016/j.jallcom. 2020.157885.
14	WANG J, LIN W Q, WU B H, et al. Syntheses and electrochemical properties of the Na-doped LiNi_0.5Mn_1.5O₄ cathode materials for lithium-ion batteries[J]. Electrochimica Acta, 2014, 145: 245-253. DOI: 10.1016/j.electacta.2014.07.140.
15	ZHANG J, CAO L H, LI J P, et al. One thousandth of quaternity slurry additive enables one thousand cycle of 5V LNMO cathode[J]. Energy Storage Materials, 2024, 64: 103060. DOI: 10.1016/j.ensm.2023.103060.
16	ZI X F, HUANG X, SONG J L, et al. Sr-Y co-doped LiNi_0.5Mn_1.5O₄ cathode material with modified crystal and improved electrochemical performance[J]. Journal of Materials Science, 2023, 58(30): 12271-12287. DOI: 10.1007/s10853-023-08793-w.
17	OH S W, PARK S H, KIM J H, et al. Improvement of electrochemical properties of LiNi_0.5Mn_1.5O₄ spinel material by fluorine substitution[J]. Journal of Power Sources, 2006, 157(1): 464-470. DOI: 10.1016/j.jpowsour.2005.07.056.
18	LUO Y Y, CUI Z, WU C X, et al. Enhanced electrochemical performance of a Ti-Cr-doped LiMn_1.5Ni_0.5O₄ cathode material for lithium-ion batteries[J]. ACS Omega, 2023, 8(25): 22721-22731. DOI: 10.1021/acsomega.3c01524.
19	LIN F C, GUO J B, WANG L Y, et al. Synergistic effect of Mg and Y co-dopants on enhancement of electrochemical properties of LiNi_0.5Mn_1.5O₄ spinel[J]. Electrochimica Acta, 2021, 399: 139433. DOI: 10.1016/j.electacta.2021.139433.
21	WANG J, NIE P, XU G Y, et al. High-voltage LiNi_0.45Cr_0.1Mn_1.45O₄ cathode with superlong cycle performance for wide temperature lithium-ion batteries[J]. Advanced Functional Materials, 2018, 28(4): 1704808. DOI: 10.1002/adfm.201704808.
22	ZHU R N, ZHANG S J, GUO Q X, et al. More than just a protection layer: Inducing chemical interaction between Li₃BO₃ and LiNi_0.5Mn_1.5O₄ to achieve stable high-rate cycling cathode materials[J]. Electrochimica Acta, 2020, 342: 136074. DOI: 10.1016/j.electacta.2020.136074.
23	CHENG J F, LI M X, WANG Y T, et al. Effects of Al and Co doping on the structural stability and high temperature cycling performance of LiNi_0.5Mn_1.5O₄ spinel cathode materials[J]. Chinese Journal of Chemical Engineering, 2023, 61: 201-209. DOI: 10.1016/j.cjche.2023.02.020.
24	CHLADIL L, KUNICKÝ D, KAZDA T, et al. In-situ XRD study of a chromium doped LiNi_0.5Mn_1.5O₄ cathode for Li-ion battery[J]. Journal of Energy Storage, 2021, 41: 102907. DOI: 10.1016/j.est.2021.102907.
25	LIU M H, HUANG H T, LIN C M, et al. Mg gradient-doped LiNi_0.5Mn_1.5O₄ as the cathode material for Li-ion batteries[J]. Electrochimica Acta, 2014, 120: 133-139. DOI: 10.1016/j.electacta.2013.12.065.
26	MANTHIRAM A, CHEMELEWSKI K, LEE E S. A perspective on the high-voltage LiMn_1.5Ni_0.5O₄ spinel cathode for lithium-ion batteries[J]. Energy & Environmental Science, 2014, 7(4): 1339-1350. DOI: 10.1039/C3EE42981D.
27	CUI X, ZHOU X, LIANG W, et al. Exploring the action mechanism of magnesium in different cations sites for LiNi_0.5Mn_1.5O₄ cathode materials[J]. Materials Today Sustainability, 2022, 17: 100105. DOI: 10.1016/j.mtsust.2021.100105.
28	LI D J, XIAO B, DAI X Y, et al. One-step in situ construction of Mg_0.5Ti₂(PO₄)₃ coating and cation doped modified LiNi_0.5Mn_1.5O₄[J]. Surface and Coatings Technology, 2024, 489: 131080. DOI: 10.1016/j.surfcoat.2024.131080.
29	WEI A J, LI W, CHANG Q, et al. Effect of Mg²⁺/F^- co-doping on electrochemical performance of LiNi_0.5Mn_1.5O₄ for 5 V lithium-ion batteries[J]. Electrochimica Acta, 2019, 323: 134692. DOI: 10.1016/j.electacta.2019.134692.
30	STÜBLE P, GEßWEIN H, INDRIS S, et al. On the electrochemical properties of the Fe-Ti doped LNMO material LiNi_0.5Mn_1.37Fe_0.1Ti_0.03O_3.95[J]. Journal of Materials Chemistry A, 2022, 10(16): 9010-9024. DOI: 10.1039/D2TA00299J.
31	MAO J, DAI K H, XUAN M J, et al. Effect of chromium and niobium doping on the morphology and electrochemical performance of high-voltage spinel LiNi_0.5Mn_1.5O₄ cathode material[J]. ACS Applied Materials & Interfaces, 2016, 8(14): 9116-9124. DOI: 10.1021/acsami.6b00877.
32	PANG W K, LU C Z, LIU C E, et al. Crystallographic origin of cycle decay of the high-voltage LiNi_0.5Mn_1.5O₄ spinel lithium-ion battery electrode[J]. Physical Chemistry Chemical Physics, 2016, 18(26): 17183-17189. DOI: 10.1039/c6cp00947f.
