A novel day-ahead-intraday low-carbon optimal scheduling method for power system source-load dispatch based on the demand response characteristics of electric vehicles

doi:10.19799/j.cnki.2095-4239.2025.0027

Abstract

Abstract:

Electric vehicles (EVs), as flexible loads in the optimal scheduling of new power systems, can enhance the utilization of new energy and offer a new way to accelerating the development of next-generation power infrastructure. To address the low-carbon optimal scheduling challenge involving sources and loads, where EVs participate in price- and incentive-based demand response, this study proposes a new day-ahead-intraday low-carbon optimal scheduling method. The approach leverages the demand response characteristics of EVs and employs the sparrow search algorithm (SSA) to optimize a convolutional long short-term memory neural network (ConvLSTM NN). First, the historical data of new energy generation and base load are predicted using the SSA-optimized ConvLSTM NN, thereby reducing the influence of uncertainties on the supply and demand sides in the day-ahead-intraday scheduling of new power systems. Next, three types of EV charging modes are defined based on their charging characteristics observed under demand response participation. A two-stage low-carbon environmental-economic dispatch model for source-load interaction is then developed, incorporating the total system cost under ladder-type carbon trading and the optimal control of pollutant emissions. Finally, an improved multiobjective gray wolf algorithm is employed to solve the model. For validation, typical daily data on photovoltaic power, wind power, and loads are used in the case analysis, which also fully considers the demand response characteristics of the various EV charging modes. The optimal scheduling results across four operating scenarios show that, compared with Scenario 1, Scenario 4 achieves a 10.3% reduction in total cost, a 10.9% decrease in pollutant emissions, and a 4.2% increase in new energy consumption. Overall, the proposed day-ahead-intraday low-carbon optimal scheduling method effectively enhances the environmental and economic benefits of new energy utilization in modern power systems.

Key words: electric vehicles, source-load prediction, new power system, day-ahead-intraday optimal scheduling, low carbon optimal scheduling

CLC Number:

TM 73

Ruoqiong LI, Yujie SI, Xin LI. A novel day-ahead-intraday low-carbon optimal scheduling method for power system source-load dispatch based on the demand response characteristics of electric vehicles[J]. Energy Storage Science and Technology, 2025, 14(8): 3170-3184.

Figures/Tables 23

Fig. 1

Fig. 2

Fig. 3

Fig. 4

Fig. 5

Table 1

Fig. 6

Fig. 7

Fig. 8

Fig. 9

Table 2

Fig. 10

Fig. 11

Fig. 12

Fig. 13

Table 3

Fig. 14

Fig. 15

Fig. 16

Table 4

Table A1

Table A2

Pollutant emission parameters of thermal power units"

机组编号

α

β

γ

ζ

λ

0.0465

0.0470

-3.9524

-3.9864

350.0056

360.0012

0.5475

0.0234

Table A2

Table A3

References 24

[1]	董昱, 孙大雁, 许丹, 等. 新型电力系统电力电量平衡的挑战、应对与展望[J]. 中国电机工程学报, 2025, 45(6): 2039-2057. DOI: 10. 13334/j.0258-8013.pcsee.240656.
	DONG Y, SUN D Y, XU D, et al. Challenges, response and prospects for power balance in new power systems[J]. Proceedings of the CSEE, 2025, 45(6): 2039-2057. DOI: 10. 13334/j.0258-8013.pcsee.240656.
[2]	易琛, 任建文, 戚建文. 考虑需求响应的风电消纳模糊优化调度研究[J]. 电力建设, 2017, 38(4): 127-134. DOI: 10.3969/j.issn.1000-7229.2017.04.017.
	YI C, REN J W, QI J W. Fuzzy optimal dispatch of wind power consumption considering demand response[J]. Electric Power Construction, 2017, 38(4): 127-134. DOI: 10.3969/j.issn.1000-7229.2017.04.017.
[3]	李灿. 促进风电消纳的直流跨区互联电网分层优化调度研究[D]. 长沙: 湖南大学, 2021. DOI: 10.27135/d.cnki.ghudu.2021.000409.
[4]	段小宇, 胡泽春, 崔岩, 等. 长时间尺度下的电动汽车有序充放电调度[J]. 电网技术, 2018, 42(12): 4037-4044. DOI: 10.13335/j.1000-3673.pst.2018.1682.
	DUAN X Y, HU Z C, CUI Y, et al. Optimal charging and discharging strategy for electric vehicles in large timescales[J]. Power System Technology, 2018, 42(12): 4037-4044. DOI: 10. 13335/j.1000-3673.pst.2018.1682.
[5]	洪睿洁, 顾丹珍, 莫阮清, 等. 基于用户偏好的电动汽车储能V2G策略优化[J]. 储能科学与技术, 2023, 12(8): 2659-2667. DOI: 10. 19799/j.cnki.2095-4239.2023.0173.
	HONG R J, GU D Z, MO R Q, et al. Research on optimization of EV energy storage V2G strategy based on user preference[J]. Energy Storage Science and Technology, 2023, 12(8): 2659-2667. DOI: 10.19799/j.cnki.2095-4239.2023.0173.
[6]	邵文锋. 计及电动汽车的综合能源系统优化调度研究[D]. 贵阳: 贵州大学, 2023. DOI: 10.27047/d.cnki.ggudu.2023.001226.
[7]	崔杨, 邓贵波, 曾鹏, 等. 计及碳捕集电厂低碳特性的含风电电力系统源-荷多时间尺度调度方法[J]. 中国电机工程学报, 2022, 42(16): 5869-5886, 6163. DOI: 10.13334/j.0258-8013.pcsee.210697.
	CUI Y, DENG G B, ZENG P, et al. Multi-time scale source-load dispatch method of power system with wind power considering low-carbon characteristics of carbon capture power plant[J]. Proceedings of the CSEE, 2022, 42(16): 5869-5886, 6163. DOI: 10.13334/j.0258-8013.pcsee.210697.
[8]	董存, 王铮, 白捷予, 等. 光伏发电功率超短期预测方法综述[J]. 高电压技术, 2023, 49(7): 2938-2951. DOI: 10.13336/j.1003-6520.hve.20220974.
	DONG C, WANG Z, BAI J Y, et al. Review of ultra-short-term forecasting methods for photovoltaic power generation[J]. High Voltage Engineering, 2023, 49(7): 2938-2951. DOI: 10.13336/j. 1003-6520.hve.20220974.
[9]	韩富佳, 王晓辉, 乔骥, 等. 基于人工智能技术的新型电力系统负荷预测研究综述[J]. 中国电机工程学报, 2023, 43(22): 8569-8592. DOI: 10.13334/j.0258-8013.pcsee.221560.
	HAN F J, WANG X H, QIAO J, et al. Review on artificial intelligence based load forecasting research for the new-type power system[J]. Proceedings of the CSEE, 2023, 43(22): 8569-8592. DOI: 10.13334/j.0258-8013.pcsee.221560.
[10]	钱政, 裴岩, 曹利宵, 等. 风电功率预测方法综述[J]. 高电压技术, 2016, 42(4): 1047-1060. DOI: 10.13336/j.1003-6520.hve.2016 0405021.
	QIAN Z, PEI Y, CAO L X, et al. Review of wind power forecasting method[J]. High Voltage Engineering, 2016, 42(4): 1047-1060. DOI: 10.13336/j.1003-6520.hve.20160405021.
[11]	孔祥玉, 马玉莹, 艾芊, 等. 新型电力系统多元用户的用电特征建模与用电负荷预测综述[J]. 电力系统自动化, 2023, 47(13): 2-17. DOI: 10.7500/AEPS20230312004.
	KONG X Y, MA Y Y, AI Q, et al. Review on electricity consumption characteristic modeling and load forecasting for diverse users in new power system[J]. Automation of Electric Power Systems, 2023, 47(13): 2-17. DOI: 10.7500/AEPS20230312004.
[12]	马雨桐. 基于混合长短期记忆神经网络的居民用电负荷优化研究[D]. 北京: 华北电力大学, 2021. DOI: 10.27140/d.cnki.ghbbu. 2021.000816.
[13]	高犁. 基于SSA-LSTM模型的短期电力负荷预测研究[D]. 淮南: 安徽理工大学, 2022. DOI: 10.26918/d.cnki.ghngc.2022.000619.
	GAO L. Short-term power load prediction based on SSA-LSTM model[D]. Huainan: Anhui University of Science & Technology, 2022. DOI: 10.26918/d.cnki.ghngc.2022.000619.
[14]	程锟. 基于V2G技术的电动汽车集群并网控制与实时优化调度研究[D]. 沈阳: 沈阳工业大学, 2022. DOI: 10.27322/d.cnki.gsgyu. 2022.000116.
[15]	郭明星, 吕冉, 费斐, 等. 考虑电动汽车和需求响应的电-热-水多能耦合系统经济调度[J]. 中国电力, 2022, 55(12): 105-111.
	GUO M X, LV R, FEI F, et al. Economic scheduling of electric-heat-water multi-energy coupling systems considering electric vehicles and demand response[J]. Electric Power, 2022, 55(12): 105-111.
[16]	周星月, 李晓皓, 王智东, 等. 计及预测负荷和用户需求差异的电动汽车实时调度优化[J]. 全球能源互联网, 2022, 5(6): 543-551. DOI: 10.19705/j.cnki.issn2096-5125.2022.06.003.
	ZHOU X Y, LI X H, WANG Z D, et al. Real-time scheduling optimization of electric vehicles considering the predicted load and the difference between users' demand[J]. Journal of Global Energy Interconnection, 2022, 5(6): 543-551. DOI: 10.19705/j.cnki.issn2096-5125.2022.06.003.
[17]	王利杰. 计及EV和PV接入电力系统环境经济调度研究[D]. 武汉: 湖北工业大学, 2019.
	WANG L J. Study on environmental and economic dispatch of power system considering EV and PV access[D]. Wuhan: Hubei University of Technology, 2019.
[18]	王浩, 袁至, 李骥, 等. 考虑综合需求响应的含光热电站的综合能源系统低碳优化调度[J]. 现代电子技术, 2023, 46(14): 107-114. DOI: 10.16652/j.issn.1004-373x.2023.14.019.
	WANG H, YUAN Z, LI J, et al. Low-carbon optimal scheduling of integrated energy system with photo-thermal power station considering comprehensive demand response[J]. Modern Electronics Technique, 2023, 46(14): 107-114. DOI: 10.16652/j.issn.1004-373x.2023.14.019
[19]	张彩玲, 王爽, 葛淑娜, 等. 计及灵活需求响应和碳-绿证交易的综合能源系统优化调度[J]. 中国电力, 2024, 57(5): 14-25. DOI: 10. 11930/j.issn.1004-9649.202305134.
	ZHANG C L, WANG S, GE S N, et al. Optimal scheduling of integrated energy systems considering flexible demand response and carbon emission-green certificate joint trading[J]. Electric Power, 2024, 57(5): 14-25. DOI: 10.11930/j.issn.1004-9649. 2023 05134.
[20]	白英杰. 采用多目标优化算法的含风电电力系统环境经济调度研究[D]. 镇江: 江苏科技大学, 2021. DOI: 10.27171/d.cnki.ghdcc. 2021.000370.
[21]	杨晓辉, 王晓鹏, 邓叶恒. 含电动汽车的主动配电网多目标分层优化调度[J]. 电力工程技术, 2024, 43(4): 156-165.
	YANG X H, WANG X P, DENG Y H. Multi-objective hierarchical optimization dispatch of active distribution network with electric vehicles[J]. Electric Power Engineering Technology, 2024, 43(4): 156-165.
[22]	张良, 郑丽冬, 冷祥彪, 等. 基于灰狼算法的风-光-抽水蓄能联合系统多目标优化策略[J]. 上海交通大学学报, 2024, 58(10): 1554-1566. DOI: 10.16183/j.cnki.jsjtu.2023.049.
	ZHANG L, ZHENG L D, LENG X B, et al. Multi-objective optimization strategy for wind-photovoltaic-pumped storage combined system based on gray wolf algorithm[J]. Journal of Shanghai Jiao Tong University, 2024, 58(10): 1554-1566. DOI: 10.16183/j.cnki.jsjtu.2023.049.
[23]	周波. 基于灰狼优化算法的楼宇负荷多目标优化调度研究[D]. 湘潭: 湘潭大学, 2020. DOI: 10.27426/d.cnki.gxtdu.2020.000399.
	ZHOU B. Research on multi-objective optimal scheduling of building load based on grey wolf optimization algorithm[D]. Xiangtan: Xiangtan University, 2020. DOI: 10.27426/d.cnki.gxtdu. 2020.000399.
[24]	李佳瑶, 刘伟娜. 考虑碳交易和风荷预测误差的电力系统低碳经济调度[J]. 浙江电力, 2021, 40(5): 1-6. DOI: 10.19585/j.zjdl.2021 05001.
	LI J Y, LIU W N. Low-carbon economic dispatch of power system considering carbon trading and wind power and load forecast errors[J]. Zhejiang Electric Power, 2021, 40(5): 1-6. DOI: 10. 19585/j.zjdl.202105001.

调度结果	场景1	场景2	场景3	场景4
系统总成本/USD	64434	62850	60786	58929
启停成本/USD	320	380	290	290
运行成本/USD	63185	61761	59867	58344
弃光成本/USD	235	143	120	102
弃风成本/USD	694	461	198	39
碳交易成本/USD	0	105	0	-165
弃光率/%	6.13	3.75	3.13	2.84
弃风率/%	6.38	4.24	1.82	0.37
日前IDR成本/USD	0	0	311	319
污染物排放/lb	7932	7558	7292	7126

调度结果	场景1	场景2	场景3	场景4
系统总成本/USD	62963	60336	58511	56454
运行成本/USD	62339	59856	58162	56341
弃光成本/USD	49	22	15	10
弃风成本/USD	575	360	88	32
碳交易成本/USD	0	98	0	-187
弃光率/%	1.28	0.58	0.41	0.26
弃风率/%	5.17	3.25	0.79	0.29
日内IDR成本/USD	0	0	246	258
污染物排放/lb	7785	7456	7143	6937

评价指标	MAPE/%	RMSE/MW
BP神经网络	5.27	0.73
Elman神经网络	7.13	1.01
CNN-LSTM神经网络	4.22	0.7
GA-CNN-LSTM神经网络	2.91	0.38
SSA-CNN-LSTM神经网络	2.31	0.37

算法	目标	排放污染物/10³ lb	经济成本/10⁴ USD
传统MOGWO	经济最优	7.2612	5.5323
	环境最优	6.8445	5.8617
	折中解	6.9527	5.6593

改进MOGWO	经济最优	7.2858	5.5129
	环境最优	6.8356	5.8941
	折中解	6.9371	5.6454

机组编号	最大出力/MW	最小出力/MW	起停成本/USD	成本系数a/b/c/(USD/MW²)/(USD/MW)/USD	最小启停时间/h	机组爬坡/MW/h	碳排放强度/(t/MWh)
1	80	10	170	0.00712/22.3/480	3/3	20	1.05
2	40	5	30	0.00413/25.9/660	1/1	5	1.12
3	40	2	30	0.00222/27.3/665	1/1	5	1.15
